Image writing

Function method: cv2.imwrite('yahboom1.jpg', img).

The first parameter is the saved file name, and the second parameter is the saved image.

Below we demonstrate the method of image writing. First read an image yahboom.jpg, and then write yahboom1.jpg.

Code path:

x
~/dofbot_ws/src/dofbot_opencv/scripts/1.OpenCV_basic/02_write_pic.ipynb

xxxxxxxxxx
import cv2
# 1 File reading 2 Packaging format analysis 3 Data decoding 4 Data loading
img = cv2.imread('yahboom.jpg', 1)
# cv2.imshow('yahboom, img) #See the explanation below
cv2.imwrite('yahboom1.jpg', img) # 1 name 2 dat

The cv2.imshow('yahboom, img) function in jupyLab cannot be executed. If you need to use this sentence to display the read image, you need to execute the python file through the command: python3 XX.py

xxxxxxxxxx
#bgr8 to jpeg format
import enum
import cv2
def bgr8_to_jpeg(value, quality=75):
      return bytes(cv2.imencode('.jpg', value)[1])

xxxxxxxxxx
import ipywidgets.widgets as widgets
image_widget =   widgets.Image(format='jpg', width=320, height=240)
display(image_widget)
img = cv2.imread('yahboom1.jpg',1)
image_widget.value =   bgr8_to_jpeg(img)

When the code block is run, you can see that the yahboom.jpg image is written to yahboom1.jpg.
