Picture cut

First read the image, and then get the pixel area in the array.

In the following code, select the shape area X: 300-500 Y: 500-700. Because the image size is 800*800, the selected area should not exceed this resolution.

Code path:

x
~/dofbot_ws/src/dofbot_opencv/scripts/2.Transform/02_cut_pic.ipynb

​x
import cv2
img = cv2.imread('yahboom.jpg',   1)
dst =   img[500:700,300:500]  #Select a rectangular area X：300-500    Y：500-700
#cv2.imshow('image',dst)
​
#cv2.waitKey(0)

The following will show the comparison of the two compressed images in the jupyterLab.

xxxxxxxxxx
#bgr8转jpeg格式
import enum
import cv2
def   bgr8_to_jpeg(value, quality=75):
    return bytes(cv2.imencode('.jpg',   value)[1])

Below are the before and after images:

xxxxxxxxxx
import   ipywidgets.widgets as widgets
image_widget1   = widgets.Image(format='jpg', )
image_widget2   = widgets.Image(format='jpg', )
# display   the container in this cell's output
display(image_widget1)
display(image_widget2)
img1 =   cv2.imread('yahboom.jpg',1)
​
image_widget1.value   = bgr8_to_jpeg(img1)  #The original image
image_widget2.value   = bgr8_to_jpeg(dst)   #The image after cutting

After the program is run, we can see that some parts have been cut out, as shown in the following figure.
